Technical Bulletin PAGE: 5/9
Model: Model U-P1 Date: 3-Feb-03 No.: RG071003
10 H:OHP/1C
Sets the heating roller temperature for OHP sheets in
single-color mode.
[120 ~ 190 / 165 (170) / 1°C/step]
11 H: OHP/FC
Sets the heating roller temperature for OHP sheets in
full-color mode.
[120 ~ 190 / 175 (180) / 1°C/step]
12 H: Duplex/1C
Sets the heating roller temperature for duplex printing
(both sides) in single-color mode.
[120 ~ 190 / 150 (155) / 1°C/step]
13 H: Duplex/FC
Sets the heating roller temperature for duplex printing
(both sides) in full-color mode.
[120 ~ 190 / 155 (165) / 1°C/step]
14 P: Pre
Sets the temperature at which the pressure roller starts
idling .
[10 (30) ~ 100 / 10 (30) / 1°C/step]
15 P: _Ready
Sets the temperature at which the pressure roller
becomes ready for printing.
[60 ~ 150 / 65 (80) / 1°C/step]
16 P: _Standby Sets the pressure roller temperature for the ready
(standby) condition. After the main switch has been
turned on, the machine enters this condition when the
pressure roller temperature reaches the temperature
specified in this SP mode. When the machine is
recovering from energy saver or auto off mode, the
machine becomes ready when both heat and pressure
roller temperatures reach the specified temperature.
Heating roller: SP1-105-3
[60 ~ 150 / 110 (120) / 1°C/step]
27 H: OFFSET+
Sets the heating roller temperature correction for when
room temperature is 15°C or lower.
[0 ~ 20 / 5 / 1°C/step]
28 P: OFFSET+
Sets the pressure roller temperature correction for when
room temperature is 15°C or lower.
[0 ~ 20 / 0 / 1°C/step]
29 H: OFFSET–
Sets the heating roller temperature correction for when
room temperature is 30°C or higher.
[0 ~ 20 / 5 / 1°C/step]
105*
30 P: OFFSET–
Sets the pressure roller temperature correction for when
room temperature is 30°C or higher.
[0 ~ 20 / 0 / 1°C/step]
To Next Page
