Ricoh M C250FW - Printing Confidential Documents

4.Replacement and Adjustment
79
5. Open the fusing exit guide plate [A] to remove it.
6. Remove the stay [A].
7. Remove the pressure roller thermistor assembly, and then remove the pressure roller thermistor
(center) (TH3) [A].
Fusing Sleeve Belt Unit
Fusing sleeve belt unit will be available as a service parts around Nov 2019.
