Ricoh MP 7503 User Manual

Step 3: Specifying access privileges for the created shared folder
If you want to specify access privileges for the created folder to allow other users or groups to access
the folder, configure the folder as follows:
1. Right-click the folder created in Step 2, and then click [Properties].
2. On the [Security] tab, click [Edit...].
3. Click [Add...].
4. In the [Select Users or Groups] window, click [Advanced...].
5. Specify one or more object types, select a location, and then click [Find Now].
6. From the list of results, select the groups and users you want to grant access to, and then
click [OK].
7. In the [Select Users or Groups] window, click [OK].
8. In the [Groups or user names:] list, select a group or user, and then, in the [Allow] column
of the permissions list, select either the [Full Control] or [Modify] check box.
9. Click [OK].
Registering an SMB Folder
1. Press [Home] ( ) at the bottom of the screen in the center.
2. Flick the screen to the left, and then press the [Address Book Management] icon.
3. Check that [Program / Change] is selected.
4. Press [New Program].
5. Press [Change] under "Name".
The name entry display appears.
6. Enter the name, and then press [OK].
7. Press [ Next].
8. Press the key for the classification you want to use under "Select Title".
Basic Procedure When Using Scan to Folder
103

Ricoh MP 7503 Specifications

General

Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Monthly Duty Cycle	300, 000 pages
Functions	Print, Copy, Scan, Fax
Automatic Document Feeder (ADF)	Yes
ADF Capacity	220 sheets
Scan Resolution	600 dpi
Memory (RAM)	4 GB
Hard Disk Drive	320 GB
Print Speed	75 ppm
Paper Capacity	4, 300 sheets standard
Scan Speed	120 ipm
Connectivity	Ethernet, USB
Copy Speed	75 ppm (Black)
Zoom Range	25% - 400%
Fax Speed	33.6 Kbps
Interface	USB 2.0, Ethernet
Operating Systems Supported	Windows, Mac, Linux
Power Consumption	1.5 kW
