8
The MP 6200SR Series
The SCSI ID number is decided by which of the jumper pins Nos.2,3 and 4 are
connected.
Refer to the following diagram when changing the SCSI ID.
SCSI ID Pin No.2 Pin No.3 Pin No.4 Jumper Note
0 OFF OFF OFF
2 3 4
Initial setting
1 ON OFF OFF
2 3 4
2 OFF ON OFF
2 3 4
3 ON ON OFF
2 3 4
4 OFF OFF ON
2 3 4
5 ON OFF ON
2 3 4
6 OFF ON ON
2 3 4
7ONONON
2 3 4
The initial setting for the SCSI interface board is generally set at
SCSI ID 7. Confirm the SCSI ID of the SCSI interface board before
setting other numbers.
SCSI board
initial setting
