TABLE 1-1: S-SERIES PERSONAL LIFT TERMINOLOGY
REF NAME DESCRIPTION
1 Left
Position references when lift is viewed from outside of vehi-
cle.
2 Right
3 Front
4 Rear
5 Hydraulic Cylinder
(Left and Right) Telescoping steel tube which converts hy-
draulic pressure into lifting force.
6
Hydraulic Power
Unit
Contains pump used to create hydraulic pressure to raise
and fold lift, as well as a valve to unfold and lower lift.
7
Manual Backup
Pump Handle
Used to operate manual back up-pump when electrical
power is not functional.
8 Baseplate Assembly
Assembly that bolts securely to vehicle floor.
9
Serial Number
Location
Location of lift serial number decal.
10 Top/Bottom Arms
(Left/Right) Upper and lower links connecting vertical arm
to base assembly.
11 Vertical Arm (Left/Right) Connects platform and top/bottom arms.
12 Handrails (Left/Right) Provide a hand-hold for platform occupant.
13 Control Pendant Hand-held device used to control lift operating functions.
14 Platform Rollstop
Front barrier prevents wheelchair from slow, inadvertent
rolling off of platform during lift operation.
15 Platform
Component of lift where wheelchair and occupant sit during
"Up" and "Down" operations.
16
Inboard Rollstop
(Bridgeplate)
Front barrier prevents wheelchair from slow, inadvertent
rolling off of platform during lift operation.
17 Handrail Switch
Alternate switch that may be used by platform occupant to
raise and lower lift.
18 Tie-Rod Assembly
(Left and Right) Links used on split platform models only
that cause platform to split as it deploys (unfolds).
END OF TABLE
