TABLE 3-1: MAINTENANCE SCHEDULE
SERVICE
POINT
ACTION TO PERFORM
Handrails Verify that handrail fasteners are properly tightened.
Lift Mounting
Points
§ Verify that vehicle mounting and support points are undamaged.
§ Verify that mounting bolts are sufficiently tight.
Main Lifting
Pivots
Verify that arm pins are properly installed, free from damage, and locked
in position.
Platform Pivot
Points
Verify that platform moves freely, without binding, and does not wobble.
Bridgeplate
(Inner rollstop)
§ Verify that bridgeplate operates without binding during lift functions.
§ Verify that bridgeplate deploys fully when platform stops at floor
level.
§ Verify bridgeplate rests flat against baseplate.
Front Rollstop § Verify that rollstop opens completely when platform contacts ground.
§ Verify that rollstop closes and locks when platform leaves ground.
CAUTION
Check and add fluid when platform is at GROUND level. Fluid that is
added when platform is raised will overflow when platform is lowered.
§ Verify that pump hydraulic fluid level is at FULL mark when platform
is at ground level. Add Texaco 01554 Aircraft Hydraulic Oil or
equivalent U.S. mil spec H5606G fluid.
§ Verify there are no hydraulic fluid leaks.
Hydraulic Power
Unit
§ Verify that manual release valve is closed.
SIX MONTH SAFETY CHECK (or 1750 cycles of operation)
Handrails
Verify that all handrail fasteners are properly tightened.
Cleaning and
Lubrication
1. Clean lift with mild soap and water and wipe dry. Prevent rust by
coating all surfaces with a light oil. Remove excess oil.
2. Spray penetrating oil (Curtisol Red Grease 88167 or WD-40)
where specified in Figure 3-1, following directions on container.
Remove excess grease from surrounding areas.
CAUTION
The annual safety check must be performed by a Ricon authorized dealer.
ANNUAL SAFETY CHECK (or 3500 cycles of operation)
Hydraulic Cylin-
der, Hoses and
Fittings
§ Check hydraulic cylinder for evidence of leaks.
§ Inspect hydraulic hoses for damage.
§ Verify that all fittings are tight.
END OF TABLE
