Riedel Performer C3 - Page 55

PERFORMER Digital Partyline, User Manual, Version 2.30
Pin Out: GPI Out - D-SUB 25 Connector
PIN Signal GPO Function
1 OUT1 A CALL A Line #1
2 OUT2 A CALL B Line #1
3 OUT3 A SCALLA Line #1
4 OUT4 A CALL A Line #2
5 OUT5 A CALL B Line #2
6 OUT6 A SCALLA Line #2
7 OUT7 A CALL A Line #3
8 OUT8 A CALL B Line #3
9 OUT9 A SCALLA Line #3
10 OUT10A CALL A Line #4
11 OUT11A CALL B Line #4
12 OUT12 A SCALLA Line #4
13 +5V
14 OUT1 B CALL A Line #1
15 OUT2 B CALL B Line #1
16 OUT3 B SCALLA Line #1
17 OUT4 B CALL A Line #2
18 OUT5 B CALL B Line #2
19 OUT6 B SCALLA Line #2
20 OUT7 B CALL A Line #3
21 OUT8 B CALL B Line #3
22 OUT9 B SCALLA Line #3
23 OUT10B CALL A Line #4
24 OUT11B CALL B Line #4
25 OUT12 B SCALLA Line #4
Page 55
