PRINCIPAL ELEMENTS OF THE MOTORCYCLE
KEYS
With this model, you will be given a set of keys, which are used for the Ignition switch/Steering lock.
These keys are joined together by a small plastic panel, where the key number is engraved. We recom-
mend that this number is kept in a safe place in case the keys are lost.
INSTRUMENT AND INDICATORS
1-.MainIgnitionswitch
The Ignition switch has three positions: the Ignition off position, the start or Ignition on position and a
third position which switches on the front and rear lights of the bike.
2-. Speedometer (Kmh and Mph)
The speedometer has the odometer fitted, which is calibrated in kilometres
4-. Out of gear (Neutral) indicator (Green.)
This light comes on when the gear change lever is in the neutral (N) position, that is to say, out of gear.
5-. Temperature warning lamp (Red.)
This light is very important as it can tell us if there is an excessive increase in engine running temperatu-
re due to an engine fault or a low level of cooling liquid in the radiator.
6
