GEARBOX OIL CHANGE.
The gearbox and the clutch are lubricated by the
action of the same gearbox oil. The recommen-
ded oil is SAE 10W/30, with a total gearbox
capacity of 820c.c.
A drainage bolt situated in the bottom right-hand
side of the motor empties the gearbox. It is
recommended that you change the oil when the
motor is still warm, as the oil will flow easier.
Remove the drain plug and wait for the gearbox
to empty completely.
Once it’s empty, replace the drain plug. Remove
level plug (See picture.) Fill the gearbox through
the black plastic filler cap on the top of the gear-
box), until the oil just starts to run out of the level
hole.
27
Drainage bolt
Drain plug
Level hole
