Sensor Specifications
INPUT PARAMETERS
SUPPLY VOLTAGE
+11..36 VDC Non-Regulated
SUPPLY CURRENT
1
22mA @ 24VDC (Digital Output only)
30mA nominal @ 24VDC (Analog Output - no load)
75mA max @ 24VDC (Analog and Digital Outputs enabled)
85mA max @ 12VDC (Analog and Digital Outputs enabled)
ANALOG MEASURING RANGE
Scalable within 360°
DIGITAL MEASURING RANGE
±180°
INPUT PROTECTION
Reverse Polarity, ESD & Surge Protected
ABSOLUTE ACCURACY OVER FULL OPERATING TEMPERATURE
RANGE: ±180°
±0.1º typical, ±0.2º absolute max
RESOLUTION
0.05º
RESPONSE TIME
6 user-configurable options from 4Hz to 0.3Hz
CURRENT & VOLTAGE OUTPUT PARAMETERS
OUTPUT RANGES
Current
4..20 mA, 0..20 mA
(Configurable within 0..24mA)
Voltage
0..5 V, 0..10V
(Configurable within 0..10V)
1kΩ load min.
SENSITIVITY
2
Relative to Scaled Range
NULL (0º)
Fully Configurable
SWITCH OUTPUT PARAMETERS
OUTPUT MODE
Open Collector Switch to Signal Common
TRIP MODES
Fully Configurable (Window, Threshold, etc.)
SWITCH CAPABILITY
250mA @ 36V max
DIGITAL OUTPUT PARAMETERS
OUTPUT TYPE
RS-485 Half Duplex (2-wire)
INCLINATION OUTPUT
32-Bit IEEE Packetized Float
BAUD RATE
125K Default (Configurable from 9600 to 250K)
INFORMATION RATE
Polled (up to 20 times/sec)
LOGGING CAPABILITY (OPTIONAL)
SUPPLY CURRENT
Additional 20mA @24VDC
LOGGING RESOLUTION
Configurable in one minute increments
CARD TYPE µSD
Notes:
1. Supply Current varies depending on outputs connected. Digital output only assumes analog output section is always
active however current loop is not connected.
2. See Sensitivity & Zero Angle Calculation (Voltage and Current Outputs Only)
