Sensor Specifications, Continued
TEMPERATURE RANGES
OPERATING TEMPERATURE
-40ºF..+185ºF (-40ºC..+85ºC)
STORAGE TEMPERATURE
-49ºF..+194ºF (-45ºC..+90ºC)
MECHANICAL CHARACTERISTICS
HOUSING
Aluminum, IP68, All-weather, Submersible
WEIGHT
18.6 oz. (525 Grams)
MOUNTING HOLES
Accept #8 or M4.5 screws (See Dimensional Drawing)
MOUNTING PLANE
Flat Horizontal or Vertical Surface
OUTLINE DIMENSIONS
4.34” x 3.26” x 1.8” [110mm x 82.8mm x 45.7mm]
ELECTRICAL CONNECTION
See Electrical Connection Drawing
