Horizontal Mount Axis Orientations
As shown in the top drawing of
, the 0° orientation for a horizontal mount H6 is a desktop level position.
• For the X-axis, looking at the unit from the side with the connector facing to the right, a clockwise
rotation from the zero position is considered positive and a counter-clockwise rotation from the zero
position is considered negative.
• For the Y-axis, looking at the unit from the front with the connector facing towards you, a clockwise
rotation from the zero position is considered positive and a counter-clockwise rotation from the zero
position is considered negative.
Vertical Mount Axis Orientations
As shown in the bottom drawing of
Figure 2: Mounting Positions
