Riello AMD AN Series User Manual

AMD AN
9
Pipe temp. sensor
Sensore temp. tubazione
Fan motor Motore ventilatore
CN13
CN6
CN36
CN29
CN4
CH2 CH1
CH3
CN37
CN19
T5A/250VAC
CN22 CN23
SW3 ON
SW1 ON
4321
45678321
CN1
ABC ABC
WB R
Y/G
Ambient temp. sensor
Sensore temp. ambiente
Roomcard
Contatto presenza
Fuse
Fusibile
To outdoot unit
All'unità esterna
Wired remote controller
Comando remoto a filo
3 (C)2 (L)
1 (N)
Cantralized control
Controllo
centralizzato
Remote receiver
Ricevitore telecomando
IT
7. Schemi elettrici
W Bianco
B Nero
R Rosso
Y/G Giallo/Verde
25 AN - 35 AN
EN
7. Electrical diagrams
W White
B Black
R Red
Y/G Yellow/Green
