INSTALLATION
VERTICAL INSTALLATION OF THE DVD MODELS WITH BATTERY BOX
1. Assemble the supports and the extension as shown in the figure.
2. Put the UPS and the battery box in a vertical position and place the two supports close to them.
3. Carefully insert the UPS and the battery box in the two supports.
