- MPW / MPX -
31
MultiCOM 392 must be inserted only in the slot named “RELAY SLOT”.
▪ Remove the cover of the slot dedicated to the contacts boards (RELAY SLOT) by removing the two retaining screws.
▪ Wire appropriately MultiCOM 392.
▪ Insert MultiCOM 392 in the slot dedicated to the contacts card (RELAY SLOT).
▪ Fix the cover provided with the MultiCOM 392 using the screws previously removed.
