TECHNICAL DATA
SPECIFICATIONS FOR THE CABLING OF THE NETWORK CABLE
To connect the device to the Ethernet (10Base-T) or Fast Ethernet (100Base-T) network, a UTP
(Unshielded Twisted Pair) or STP (Shielded Twisted Pair) cable with RJ45 connectors is required.
The cable must conform to the standard IEEE 802.3u 100Base-T with 2 pairs of UTP cables of
category 5 or higher. The cable between the adaptor and the hub must not be more than 100m and
not less than 2.5m.
NETWORK CABLE CONNECTIONS
Signal
Pin # to Pin #
TX+
1   1
TX-
2   2
RX+
3   3
RX-
6   6
Pins 1 and 2 must be connected to one twisted pair, pins 3 and 6 to another.
TECHNICAL SPECIFICATIONS
NetMan 202 plus
POWER SUPPLY
Input voltage
[Vdc]
12
Maximum input current
[mA]
200
ENVIRONMENTAL
CONDITIONS
Operating temperature
[°C]
0 ÷ +40
Storage temperature
[°C]
-5 ÷ +50
Operating relative humidity
[%]
80 (max)
Storage relative humidity
[%]
90 (max)
