Riello RS 70/E MZ - Page 36

36
GB
Parameter
Number of
elements
Unit of mea-
surement
Modifica-
tion
Values interval
Degree of preci-
sion
Predefined
setting
Access mode
No. par. Description Min. Max.
221
Gas: Selection of flame sensor
0 = QRB.../ QRC
1 = ION / QRA
1 - Modification 0 1 1 1 Parameters Mode
222 Gas: Selection of the pre-purging function
0 = deactivated
1 = activated
1 - Modification 0 1 1 1 Parameters Mode
223 Maximum repeats of minimum gas pressure switch intervention 1 - Modification 1 16 1 16 Parameters Mode
225 Gas: Pre-purging time 1 s Modification 20 s 60 min 0.2 s 20 s Parameters Mode
226 Gas: Pre-ignition time 1 s Modification 0.2 s 60 min 0.2 s 2 s Parameters Mode
230 Gas: Interval 1 1 s Modification 0.2 s 60 s 0.2 s 2 s Parameters Mode
232 Gas: Interval 2 1 s Modification 0.2 s 60 s 0.2 s 2 s Parameters Mode
233 Gas: Post-combustion time 1 s Modification 0.2 s 60 s 0.2 s 8 s Parameters Mode
234 Gas: Post-purging time 1 s Modification 0.2 s 108 min 0.2 s 0.2 s Parameters Mode
242 Gas: Emptying time (valve leak detection) 1 s Modification 0.2 s 3 s 0.2 s 3 s Parameters Mode
243 Gas: Atmospheric test time (valve leak detection) 1 s Modification 0.2 s 60 s 0.2 s 10 s Parameters Mode
244 Gas: Filling time (valve leak detection) 1 s Modification 0.2 s 3 s 0.2 s 3 s Parameters Mode
245 Gas: Pressure test time (valve leak detection) 1 s Modification 0.2 s 60 s 0.2 s 10 s Parameters Mode
261 Oil: Selection of flame sensor
0 = QRB.../ QRC...
1 = ION / QRA
1 - Modification 0 1 1 0 Parameters Mode
265 Oil: Pre-purging time 1 s Modification 15 s 60 min 0.2 s 15 s Parameters Mode
266 Oil: Pre-ignition time 1 s Modification 0.2 s 60 min 0.2 s 2 s Parameters Mode
270 Oil: Interval 1 1 s Modification 0.2 s 60 min 0.2 s 2 s Parameters Mode
272 Oil: Interval 2 1 s Modification 0.2 s 60 min 0.2 s 2 s Parameters Mode
273 Oil: Post-combustion time 1 s Modification 0.2 s 60 s 0.2 s 8 s Parameters Mode
274 Oil: Post-purging time 1 s Modification 0.2 s 108 min 0.2 s 0.2 s Parameters Mode
281 Oil: Selection transformer ignition phase TA
0 = brief pre-ignition (Ph38)
1 = long pre-ignition (with fan) (Ph22)
1 - Modification 0 1 1 0 Parameters Mode
400 Air / fuel modulation curve
401 Checking fuel servomotor 13 (°) Modification 0° 90° 0.1° 0°; 0°; 15°; not
defined
Parameters Mode
402 Checking air servomotor 13 (°) Modification 0° 90° 0.1° 0°; 90°; 45°; not
defined
Parameters Mode
500 Positioning of servomotors
501 Position of the fuel servomotor in absence of flame
Index 0 = standby position
Index 1 = pre-purging position
Index 2 = post-purging position
3 (°) Modification 0° 90° 0.1° 0°; 0°; 15° Parameters Mode
Start-up, calibration and operation of the burner
5
