Riello RS 70/E MZ - Page 37

37
GB
Parameter
Number of
elements
Unit of mea-
surement
Modifica-
tion
Values interval
Degree of preci-
sion
Predefined set-
ting
Access mode
No. par. Description Min. Max.
502 Position of the air servomotor in absence of flame
Index 0 = standby position
Index 1 = pre-purging position
Index 2 = post-purging position
3 (°) Modification 0° 90° 0.1° 0°; 90°; 45° Parameters Mode
545 Minimum modulation limit 1 - Modification /
zero setting
20 % 100 % 0.1 % Not defined Parameters Mode
546 Maximum modulation limit 1 - Modification /
zero setting
20 % 100 % 0.1 % Not defined Parameters Mode
600 Servomotors
645 Analogical exit configuration
0 = CC 0...10 V
1 = CC 2...10 V
2 = CC 0 / 2...10 V
1 - Modification 0 2 1 0 Parameters Mode
700 Log of the errors
701 Error chronology: 701-725.01.Code 25 - Reading only 0 255 1 0 Service Mode
• Error chronology: 701-725.02.Diagnostic code 25 - Reading only 0 255 1 0 Service Mode
• Error chronology: 701-725.03.Error class 25 - Reading only 0 6 1 0 Service Mode
• Error chronology: 701-725.04.Phase 25 - Reading only 0 255 1 0 Service Mode
• Error chronology: 701-725.05.Start-up meter 25 - Reading only 0 99999999 1 0 Service Mode
725 Error chronology: 701-725.06.Load 25 - Reading only 0 % 100 % 0.1 % 0 % Service Mode
900 Process information
903 Current output
Index 0 = fuel
Index 1 = air
2 - Reading only 0 % 100 % 0.1 % 0 % Parameters Mode
910 Servomotors active 3 - Reading only 0 1 1 0 Parameters Mode
922 Position of the servomotors
Index 0 = fuel
Index 1 = air
2 (°) Reading only -50° 150° 150° 0° Service Mode
942 Heat source active 1 - Reading only 0 255 1 0 Parameters Mode
947 Result of the sampling of the contact (codified in bits) 2 - Reading only 0 255 1 0 Parameters Mode
950 Relay request status (coded in bits) 1 - Reading only 0 255 1 0 Parameters Mode
954 Flame intensity 1 - Reading only 0 % 100 % 1 % 0 % Service Mode
961 Status of external modules and visualisation 1 - Reading only 0 255 1 0 Parameters Mode
992 Error indicators 10 - Reset 0 0xFFFFFFFF 1 0 Parameters Mode
Start-up, calibration and operation of the burner
5
