Full power bandwidth refers to the maximum frequency when the power amplifier can generate AC
output with the maximum possible amplitude and without distortion.
Full power bandwidth
SR: Slew Rate (output slew rate)
Vmax: the maximum amplitude without distortion that the amplifier can output
Note
[2]
:
Definition of Slew Rate: input a large step-function signal into the amplifier, the output slope of the
signal is saturated to a constant at a certain position. This constant is called the Slew Rate of the
amplifier.
Note
[3]
:
The specifications above are all specifications under 25℃. The range of the environment
temperature for PA1011 is from 0℃ to +35℃ and when the environment temperature is greater
than 35℃, it is recommended that users reduce the output power and the working frequency of
PA1011.
