Rigol DM3058

Chapter 2 Calibration RIGOL
DM3058/DM3058E Calibration Guide
2-3
Table 2-1 DC Voltage, DC Current and Resistance Calibration Inputs
Function Range Scale
Zero Point
Calibration Input
[1]
Gain Calibration
Input
DC Voltage
200.000 mV
short
200.000 mV
2.00000 V
short
2.00000 V
20.0000 V
short
20.0000 V
200.000 V
short
200.000 V
1000.00 V
short
1000.00 V
DC Current
200.000 μA
open
200.000 μA
2.00000 mA
open
2.00000 mA
20.0000 mA
open
20.0000 mA
200.000 mA
open
200.000 mA
2.00000 A
open
2.00000 A
10.0000 A
open
10.0000 A
Resistance
200.000 Ω
short
200.000 Ω
2.00000 kΩ
short
2.00000 kΩ
20.0000 kΩ
short
20.0000 kΩ
200.000 kΩ
short
200.000 kΩ
2.00000 MΩ
short
2.00000 MΩ
10.0000 MΩ
short
10.0000 MΩ
Note
[1]
: Use the 4-terminal short-circuiter for short-circuit.
AC Voltage and AC Current Calibrations
The AC voltage and AC current calibrations consist of the half range calibration and
gain calibration. You should first perform the half range calibration and then perform
the gain calibration. The introductions below illustrate the calibration procedures by
taking the AC voltage 200 mV scale as an example.
1. Read the "Calibration Devices" and "Test Conditions".
2. Press
to select the AC voltage measurement function. Set the range to the
200 mV scale and set the reading rate to "Slow".
3. Press ; press T/C  PSW and input the correct calibration password; set
SecrOff and press Cal  Enter.
4. Connect the voltage output terminal of the calibrator with the HI-LO input
terminal of the multimeter. Set the calibrator to output a 100 mV, 1 kHz sine
waveform (namely the half range calibration output). Turn on the output of the
calibrator and wait until the output of the calibrator becomes stable. Then, press
Middle to perform the half range calibration; the half range calibration
parameters will be displayed in the Cal M table after the half range calibration
finishes.
