Rigol DP800A Series Performance Verification Manual

RIGOL Appendix
DP800 Performance Verification Manual
2
Transient Response Time
Channel CH1 (8V/5A) CH2 (30V/2A) CH3 (-30V/2A)
Specification <50μs
DP831A
Setting
Voltage 8V 30V -30V
Current 5.3A 2.1A 2.1A
Electronic
Load Current
Setting
CCDH1 5A 2A 2A
CCDH2 2.5A 1A 1A
Measurement
Result
t
CV Programming and Readback Accuracy
Channel CH1 (8V/5A) CH2 (30V/2A) CH3 (-30V/2A)
Specification
Programming <13mV <35mV <35mV
Readback <13mV <25mV <25mV
The output voltage is 0
DP831A
Setting
Voltage 0V 0V 0V
Current 5.3A 2.1A 2.1A
Measurement
Result
U
1
U
2
Programming:
|U
1
-0|
Readback: |U
2
-U
1
|
The output voltage is U
R
[1]
DP831A
Setting
Voltage 8V 30V -30V
Current 5.3A 2.1A 2.1A
Measurement
Result
U
3
U
4
Programming:
|U
3
-U
R
[1]
|
Readback: |U
4
-U
3
|
CC Load Regulation Rate
Channel CH1 (8V/5A) CH2 (30V/2A) CH3 (-30V/2A)
Specification <750μA <450μA <450μA
DP831A
Setting
Voltage 8.4V 32V -32V
Current 5A 2A 2A
Measurement
Result
U
0
U
1
|U
1
/R
M
[2]
-U
0
/R
M
[2]
|
