Rigol DP800A Series Performance Verification Manual

RIGOL Appendix
DP800 Performance Verification Manual
6
Transient Response Time
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification <50μs
DP832A
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Electronic
Load Current
Setting
CCDH1 3A 3A 3A
CCDH2 1.5A 1.5A 1.5A
Measurement
Result
t
CV Programming and Readback Accuracy
Channel CH1 (30V/3A) CH2 (30V/3A) CH3 (5V/3A)
Specification
Programming <35mV <35mV <10mV
Readback <25mV <25mV <10mV
The output voltage is 0
DP832A
Setting
Voltage 0V 0V 0V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
1
U
2
Programming:
|U
1
-0|
Readback:
|U
2
-U
1
|
The output voltage is U
R
[1]
DP832A
Setting
Voltage 30V 30V 5V
Current 3.2A 3.2A 3.2A
Measurement
Result
U
3
U
4
Programming:
|U
3
-U
R
[1]
|
Readback:
|U
4
-U
3
|
