User’s Guide for DS1000E, DS1000D Series
Multi-function Common Menu Run Control
Knob Buttons Buttons
Trigger Control
Horizontal
Control
Vertical Control
USB Host Logic Analyzer Port Signal Input EXT Trigger Probe
Channel Input Compensation
Figure 1- 2
Front Panel Instruction
Notation definitions in this User’s Guide:
Throughout this manual, notation symbols of buttons and knobs are the same to
those on front-panel.
A box around the name of the key denotes MENU function buttons on
front-panel, such as Measure.
( ) denotes the multi-function knob .
denotes the two POSITION knobs.
denotes the two SCALE knobs.
denotes the LEVEL knob.
The name with a drop shadow denotes the menu operating key, such as
WAVEFORM soft key in STORAGE menu.
