User’s Guide for DS1000E, DS1000D Series
1-4
Figure 1- 3
Display screen (Analog channels only)
Figure 1- 4
User Interface (Analog and Digital channels)
Waveform
display window
Menu
Channel 1
Channel 2
Running status
Location of
waveform window
in memory
Trigger point in
waveform window
Digital channels
turned on
Digital channels
turned off
Running status
Channel 1
Digital
channels
Channel coupling
and vertical div.
Horizontal
time base div.
Trigger
offset
Trigger point in
memory
