Rigol DS1000D series

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
5-2
Specifications
Acquisition
Sampling Modes
Real-Time
Equivalent
Sampling Rate
1GSa/s, 200MSa/s
[1]
DS1102X
DS1052X
25GSa/s
10GSa/s
Averages
N time acquisitions, all channels simultaneously, N is
selectable from 2, 4, 8, 16, 32, 64, 128 and 256.
Inputs
Input Coupling
DC, AC, GND
Input Impedance
1MΩ± 2%, in parallel with 15pF± 3pF
Probe Attenuation Factors
1X, 5X, 10X, 50X, 100X, 500X,1000X
Maximum Input Voltage
400V (DC＋AC Peak, 1MΩ input impedance)
40V (DC+AC Peak)
[1]
Time delay between channel
(typical)
500ps
Horizontal
Sample Rate
Range
Real-Time: 13.65Sa/s-1GSa/s
Equivalent: 13.65Sa/s-25GSa/s
Waveform
interpolation
Sin(x)/x
Record Length
Channel Mode
Sample rate
Record
Length
(normal)
Record
Length
(long record)
Single channel
1GSa/s
16Kpts
N.A.
Single channel
500MSa/s
Or lower
16 Kpts
1Mpts
Double channel
500MSa/s
Or lower
8 Kpts
512Kpts
Scan speed Range
(Sec/div)
2ns/div~50s/div, DS1102X
5ns/div~50s/div, DS1052X
1-2-5 Sequence
Sample Rate and
Delay Time
± 50ppm (over any 1ms time interval)
