Rigol DS1000D series

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
5-3
Accuracy
Delta Time
Measurement
Accuracy
(Full Bandwidth)
Single-shot: ± (1 sample interval + 50ppm × reading + 0.6
ns)
>16 averages: ± (1sample interval + 50ppm × reading + 0.4
ns)
Vertical
A/D converter
8-bit resolution, each channel samples simultaneously
[2]
Volts/div Range
2mV/div~10V/div at input BNC
Maximum Input
Analog channel maximum input voltage
CAT I 300Vrms, 1000Vpk；instantaneous voltage 1000Vpk
CAT II 100Vrms，1000Vpk
RP2200 10:1：CAT II 300Vrms
RP3200 10:1：CAT II 300Vrms
RP3300 10:1：CAT II 300Vrms
Offset Range
± 40V(200mV-10V), ± 2V(2mV-100mV)
Analog Bandwidth
100MHz (DS1102D,DS1102E)
50MHz (DS1052D, DS1052E)
Single-shot
Bandwidth
80MHz (DS1102D, DS1102E)
50MHz (DS1052D, DS1052E)
Selectable Analog
Bandwidth Limit
(typical)
20MHz
Lower Frequency
Limit (AC –3dB)
≤5Hz (at input BNC)
Rise Time at BNC,
typical
<3.5ns, <7ns,
On (100M, 50M) respectively
DC Gain Accuracy
2mV/div-5mV/div:
± 4% (Sample or Average acquisition mode)
10mV/div-10V/div:
± 3% (Sample or Average acquisition mode)
DC Measurement
Accuracy, Average
Acquisition Mode
Average of ≥16 Waveforms with vertical position at zero:
± (DC Gain Accuracy× reading+0.1div+1mV)
Average of ≥16 Waveforms with vertical position not at zero:
±[DC Gain Accuracy× (reading+vertical position)+(1% of
vertical position) + 0.2div]
Add 2mV for settings from 2mV/div to 200 mV/div
