User’s Guide for DS1000E, DS1000D Series
2-98
Vertical space between cursor A and B (
△Y): Voltage between cursors
If you choose the source as LA (DS1000D series), the measurement value is as
follows:
Position of Cursor A (time cursor centered on the midpoint of screen).
Position of Cursor B (time cursor centered on the midpoint of screen).
Cursor A value: Hex.
Cursor A value: Binary.
Cursor B value: Hex.
Cursor B value: Binary.
NOTE: The values will be automatically displayed on the right upper corner of
screen when the cursor function menu is hidden or displaying other menus.
Key Points
Cursor Y: Cursors Y appear as horizontal lines on the display to measure vertical
parameters. Usually it is used to measure the Volts. When the source is set as
function, the units are assigned to the function.
Cursor X: Cursor X appears as vertical lines on the display to measure horizontal
parameters. Usually it indicates the time of trigger excursion. When the source is
set as FFT, X means frequency.
