RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
When the cursor is in Y type, a pair of horizontal cursors CurA and CurB will be
appeared in the screen, whose voltage value could be measured separately as well
as the voltage difference between them, and which will be changed with the location
of cursor if you twirl the knob
.
To do manual Cursor Measurements, please do as the following steps:
1. Select the Manual mode for cursor measurement by pressing soft button as:
Cursor→Mode→Manual.
2. Select channel Source for measurements by pressing soft button as:
Cursor→Source→CH1, CH2, MATH (FFT) or LA (DS1000D series)
NOTE: While measuring the channel of MATH, the results are valued with “d”
(division) as units.
3. Select the cursors type by pressing soft button as Cursor→Type→X or Y.
4. Move the cursors to adjust the increment between the cursors: (Details in the
following Table)
Table 2- 86 The Cursor menu
Cursor Increment Operation
Cursor A
X
Y
Turn the multifunctional knob (
) to move
cursor A horizontally
Turn the multifunctional knob (
) to move
cursor A vertically
Cursor B
X
Y
Turn the multifunctional knob (
) to move
cursor B horizontally
Turn the multifunctional knob (
) to move
cursor B vertically
NOTE: Cursor could be moved only when the curse function menu is displayed.
5. To get measurement values:
Position of Cursor A (time cursor centered on the midpoint of screen; Voltage
cursor centered on channel ground level).
Position of Cursor B (same as above).
Horizontal space between cursor A and B (
△X): Time between cursors
(1/
△X), units in Hz, kHz, MHz, GHz.
