Specifications
All specifications apply to DS1000E, DS1000D Series Oscilloscopes unless where noted. To come up to
these specifications, two conditions must be met firstly:
 The instrument must have been operated continuously for 30 minutes under the specified
operating temperature.
 Do perform Self-Calibration operation through the Utility menu if the range of operating
temperature variations up to or more than 5°C.
NOTE: All specifications are guaranteed unless where marked “typical”.
Specifications
Bandwidth
DS1102E
DS1052E
DS1102D
DS1052D
100MHz
50MHz
100MHz
50MHz
Acquisition
Sample Modes
Real-Time Sample
Equivalent Sample
Sample Rate 1GSa/s
[1]
, 500MSa/s
DS1102X
DS1052X
25GSa/s
10GSa/s
Averages
The waveform will be displayed one time while all the channels finish N
times Sample, N could be selectable from 2, 4, 8, 16, 32, 64, 128 and 256
Inputs
Input Coupling
DC, AC, GND
Input Impedance
1MΩ±2%, the input capacity is 18pF±3pF
Probe Attenuation Factors
1X, 5X, 10X, 50X, 100X, 500X,1000X
Maximum Input Voltage
400V (DC
＋
AC Peak, 1MΩ input impedance)
40V (DC+AC Peak)
[2]
Time Delay between Channel (typical)
500ps
Horizontal
Sample Rate Range
Real-Time: 13.65Sa/s-1GSa/s
Equivalent: 13.65Sa/s-25GSa/s
Waveform Interpolation
Sin(x)/x
Memory Depth
Channel
Mode
Sample rate
Memory Depth
(normal)
Memory Depth
(long memory)
Single
channel
1GSa/s 16kpts N.A.
Single
channel
500MSa/s
or lower
16kpts 1Mpts
Dual
channel
500MSa/s
or lower
8kpts N.A.
Dual
channel
250MSa/s
or lower
8kpts 512kpts
Scanning Speed Range
(Sec/div)
2ns/div~50s/div, DS1102X
5ns/div~50s/div, DS1052X
1-2-5 Sequence
Sample Rate and Delay
Time Accuracy
±50ppm (any interval ≥1ms)
Delta Time
Measurement Accuracy
(Full Bandwidth)
Single: ±(1 Sample interval + 50ppm × reading + 0.6 ns)
>16 averages: ±(1Sample interval + 50ppm × reading + 0.4 ns)
