Rigol DS1052D User Manual

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
1-4
Multi-function Common Menu Run Control
Knob Buttons Buttons
Trigger Control
Horizontal
Control
Vertical Control
USB Host Logic Analyzer Port
Signal Input EXT Trigger Probe
Channel Input Compensation
Figure 1- 2
Front Panel Instruction
2. Rear Panel
Figure 1- 3
Rear Panel Figure of DS1000E, DS1000D Series Oscilloscope
