Rigol DS1052D

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
1-12
4. Test your device with the clip.
Figure 1- 16
Digital Channel Measurement
5. Remember to connect Ground Channel to the DUT’s ground terminal.
Figure 1- 17
Connecting to the Ground
GND
