User’s Guide for DS1000E, DS1000D Series
1-17
2. The horizontal
knob moves displayed signal horizontally
on waveform window
Turn the horizontal
knob to adjust trigger offset. The waveform
will move horizontally at the same time.
Horizontal offset back to 0 shortcut key
Press the knob to set the horizontal offset to 0 as a shortcut
key
, this is especially helpful when the trigger point is far out of the screen and
want it to get back to the screen center immediately.
3. Press the MENU button to display the TIME menu.
To enter or exit the Delayed Scan mode, set the display to Y-T, X-Y or ROLL mode,
or reset the trigger offset.
Horizontal position control
Trig-Offset: The position of the practical trigger point relative to center of
the memory. Adjust the horizontal
knob
to move the trigger
point horizontally.
