General| Bandwidth | 50 MHz |
|---|---|
| Sample Rate | 1 GSa/s |
| Channels | 2 |
| Memory Depth | 1 Mpts |
| Vertical Sensitivity | 2 mV/div to 10 V/div |
| Input Impedance | 1 MΩ ± 2% || 15 pF ± 3 pF |
| Vertical Resolution | 8 bits |
| Trigger Modes | Edge, Pulse, Video, Slope, Alternate |
| Power Supply | 100-240 V AC, 45-440 Hz |
| Display | 5.7 inch TFT LCD |
| Interfaces | USB Host, USB Device, RS-232 |
| Dimensions | 303 mm x 154 mm x 133 mm |
