RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
5-5
Trigger Condition
(＞, ＜, =) positive slope, (＞, ＜, =) negative slope
Time Setting 20ns~10s
Alternate Trigger
Trigger on CH1 Edge, Pulse, Video, Slope
Trigger on CH2 Edge, Pulse, Video, Slope
Pattern Trigger
[2]
Trigger Mode D0~D15 select H, L, X, ,
Duration Trigger
[2]
Trigger Type D0~D15 select H, L, X
Qualifier
＞, ＜, =
Time Setup 20ns~10s
Measurements
Cursor
Manual Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
Track Voltage value for Y-axis waveform
Time value for X-axis waveform
Auto Cursors are visible for Automatic Measurement
Auto Measure V
pp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot,
Preshoot, Freq, Period, Rise Time, Fall Time, +Width, -Width,
+Duty, -Duty, Delay1→2
, Delay1→2 , Phas 1→2 , Phas 1→2
Remarks:
[1] When sampling is 1GSa/s, only single channel can be used.
[2] For DS1000D Series
