Key Points
Y-T: The conventional oscilloscope display format. It shows the voltage of a
waveform record (on the vertical axis) as it varies over time (on the horizontal
axis).
X-Y: XY format displays channel 1 in the horizontal axis and channel 2 in the
vertical axis.
Roll Mode: In this mode, the waveform display rolls from right to left. No
trigger or horizontal offset control of waveforms is available during Roll Mode,
and it’s only available when set to 500 ms/div or slower.
Slow Scan Mode: This mode is available when the horizontal time base is set
to 50ms/div or slower. In this mode, the oscilloscope acquires sufficient data for
the left part to the trigger point, then wait for trigger, when trigger occurs, it
continues to draw the rest part from the trigger point to the end of the right
side. When choosing this mode to view low frequency signals, it is recommended
that the channel coupling be set as DC.
Time/Div: Horizontal scale. The Time/Div control expands or compresses the
waveform.
