RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
2-31
 Use the horizontal
knob to change the position of the expanded
portion.
 Use the horizontal
knob to adjust the Delayed Scan resolution.
 To change the main time base, turn off the Delayed Scan mode.
 Since both the main and Delayed Scan are displayed; there are half as many
vertical divisions so the vertical scaling is doubled. Notice the changes in the
status bar.
Delayed Scan Shortcut Key
:
Delayed Scan function can be activated not only by menu but also by pressing
horizontal knob.
