Rigol DS1052E User Manual

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
VI
 Provide 4 types of digital filters: LPF, HPF, BPF, BRF
 Pass/Fail detection function enables to output testing results
 Math operations available to multiple waves
 Powerful PC application software UltraScope
 Standard configuration interface: USB Device, USB Host ,RS-232 and support
USB storage device storage and PictBridge print standards
 The new function “Special Mode” can meet the needs of industrial production
 Support for remote command control
 Built-in help menu enables information getting more convenient
 Multiple Language User Interface, support Chinese & English input
 Can store files into USB storage device or the internal memory
 Waveform intensity can be adjusted
 To display a signal automatically by AUTO
 Pop-up menu makes it easy to read and use
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Rigol DS1052E Specifications

General

Bandwidth	50 MHz
Sample Rate	1 GSa/s
Channels	2
Memory Depth	1 Mpts
Vertical Sensitivity	2 mV/div to 10 V/div
Input Impedance	1 MΩ ± 2% || 15 pF ± 3 pF
Vertical Resolution	8 bits
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Power Supply	100-240 V AC, 45-440 Hz
Display	5.7 inch TFT LCD
Interfaces	USB Host, USB Device, RS-232
Dimensions	303 mm x 154 mm x 133 mm
