8 RP1000D User’s Guide
Specifications
Technical Specifications
RP1025D:
Bandwidth
X50 or X200 attenuation ratio: DC - 25MHz
(-3dB)
X20 attenuation ratio: DC - 15MHz
Attenuation Ratio
X20, X50, X200
Accuracy
±2%
Input Voltage
Range (DC + AC
peak-peak value)
X20 attenuation ratio: ≤ 140Vpp, about
50Vrms or DC
X50 attenuation ratio: ≤ 350Vpp, about
125Vrms or DC
X200 attenuation ratio: ≤ 1400Vpp, about
500Vrms or DC
Maximum Input
Voltage
Maximum differential voltage: 1400V
(DC+AC peak-peak value) or 500Vrms
Voltage to ground at the input terminal:
600Vrms
Input Impedance
Differential: 4MΩ/1.2pF
Single-ended and to ground: 2MΩ/2.3pF
Output Voltage
≤ ±6.5V
Output
Impedance
50Ω
Rise Time
X50 or X200 attenuation ratio: 14ns
X20 attenuation ratio: 23.4ns
Common-mode
Rejection
60Hz: > 80dB
100Hz: > 60dB
1MHz: > 50dB
Power Supply
Specified external 9V DC power supply
(must be specified products acknowledged
by
RIGOL
)
Power
Consumption
0.4 watt
