RIGOL
10 RP1000D User’s Guide
RP1100D:
Bandwidth
X200, X500 or X1000 attenuation ratio: DC
- 100MHz (-3dB)
X100 attenuation ratio: DC - 50MHz
Attenuation Ratio
X100, X200, X500, X1000
Accuracy
±2%
Input Voltage
Range (DC + AC
peak-peak value)
X100 attenuation ratio: ≤ 700Vpp, about
230Vrms or DC
X200 attenuation ratio: ≤ 1400Vpp, about
460Vrms or DC
X500 attenuation ratio: ≤ 3500Vpp, about
1140Vrms or DC
X1000 attenuation ratio: ≤ 7000Vpp,
about 2300Vrms or DC
Maximum Input
Voltage
Maximum differential voltage: 7000V
(DC+AC peak-peak value) or 2300Vrms
Voltage to ground at the input terminal:
6500Vrms
Input Impedance
Differential: 100MΩ/1.2pF
Single-ended and to ground: 50MΩ/2.3pF
Output Voltage
≤ ±8.0V
Output
Impedance
50Ω
Rise Time
X200, X500 or X1000 attenuation ratio:
3.5ns
X100 attenuation ratio: 7ns
Common-mode
Rejection
60Hz: > 80dB
100Hz: > 60dB
1MHz: > 50dB
Power Supply
Specified external 9V DC power supply
(must be specified products acknowledged
by RIGOL)
Power
Consumption
0.4 watt
