RIGOL Chapter 2 To Set the Vertical System
2-6 MSO1000Z/DS1000Z User’s Guide
Select "A
a
" using and press down to switch it to "
a
A". Select "C" using
and press down
to input the character. Use the same method to input "hn1".
After finishing the input, press OK to finish the editing. If the Display is enabled,
the label
will be displayed at the left of CH1 waveform.
To modify or delete the input character, press Name to select the "Name Input Area"
and use
to select the character to be modified or deleted. Enter the desired
character or press Delete to delete the character selected.
