13. Analog Channel Label/Waveform
Different channels are marked with different colors and the colors of the channel
label and waveform are the same.
14. CH2 Vertical Scale
Display the voltage value per grid of CH2 waveform vertically.
Use VIRTICAL
SCALE of CH2 to modify this parameter.
The following labels will be displayed according to the current channel
setting: channel coupling (e.g.
), input impedance (e.g. ) and
bandwidth limit (e.g.
).
15. Digital Channel Status Area
Display the current status of the 16 digital channels (D0 to D15 from right to
left). The digital channels currently turned on are displayed in green and the
digital channel currently selected is displayed in red. The digital channels turned
off are displayed in grey in the digital channel area. Note: This function is only
applicable to MSO2000A and MSO2000A-S models oscilloscopes.
16. Message Box
Display the prompt messages.
17. Source1 Waveform
Display the type of waveform currently set for Source1.
When the impedance of source 1 is set to 50 Ω,
will be displayed at the
right of the Source1 waveform.
When the modulation of source 1 is enabled,
will be displayed at the
right of the Source1 waveform.
Only available for MSO2000A-S and DS2000A-S models oscilloscopes.
18. Source2 Waveform
Display the type of waveform currently set for Source2.
When the impedance of source 2 is set to 50 Ω,
will be displayed at the
right of the Source2 waveform.
When the modulation of source 2 is enabled,
will be displayed at the
right of the Source2 waveform.
Only available for MSO2000A-S and DS2000A-S models oscilloscopes.
