Table of Contents

Guaranty and Declaration3
Safety Requirement4
- General Safety Summary4
- Safety Terms and Symbols7
- Allgemeine Sicherheits Informationen8
- Sicherheits Begriffe und Symbole11
- Measurement Category12
- Ventilation Requirement13
- Working Environment14
- General Care and Cleaning16
- Environmental Considerations17
MSO4000/DS4000 Series Overview18
Document Overview20
- Table of Contents24
Chapter 1 Quick Start31
- General Inspection32
- Appearance and Dimensions33
- To Prepare the Oscilloscope for Use34
- Front Panel Overview46
- Rear Panel Overview47
- Front Panel Function Overview49
- User Interface59
- To Use the Security Lock66
- To Use the Built-In Help System67
Chapter 2 Vertical System Setting69
- To Turn the Analog Channel On/Off70
- To Adjust the Vertical Scale71
- To Adjust the Vertical Position72
- To Specify the Channel Coupling73
- To Specify the Bandwidth Limit74
- To Set the Probe75
- To Specify the Input Impedance80
- To Turn Waveform Invert On/Off81
- To Specify the Vertical Reference81
- To Specify the Amplitude Unit82
- To Set the Channel Label83
- To Set the Delay Calibration85
Chapter 3 Horizontal System Setting87
- To Adjust the Horizontal Time Base88
- To Adjust the Horizontal Position89
- To Specify the Time Base Mode90
- To Turn Delayed Sweep On/Off96
- To Specify the Horizontal Reference99
Chapter 4 Sample System Setting101
- Sample Mode102
- Sample Rate103
- LA Sample Rate105
- To Specify the Acquisition Mode106
- To Set the Memory Depth109
- To Turn Anti-Aliasing On/Off111
Chapter 5 Trigger113
- Trigger Source115
- Trigger Level/Threshold Level117
- Trigger Mode118
- Trigger Coupling120
- Trigger Holdoff121
- Noise Rejection122
- Trigger Output Connector122
- Edge Trigger123
- Pulse Trigger125
- Runt Trigger128
- Nth Edge Trigger132
- Slope Trigger135
- Video Trigger140
- Pattern Trigger143
- RS232 Trigger146
- I2C Trigger150
- SPI Trigger154
- CAN Trigger157
- Flexray Trigger162
- USB Trigger165
Chapter 6 Operations and Measurements167
- To Make Math Operation168
- To Make Auto Measurement186
- To Make Cursor Measurement203
Chapter 7 Logic Analyzer221
- To Turn the Digital Channels On/Off222
- To Arrange the Digital Channels223
  - User-Defined Arrangement223
  - Auto Arrangement224
- To Perform Grouping Setting224
- To Specify the Waveform Display Size225
- To Adjust the Threshold Level226
- To Use the Digital Bus227
- To Set the Digital Channel Label230
- To Set the Delay Calibration of the Digital Channels231
- Digital Channel Waveform and Label Colors232
Chapter 8 Protocol Decoding233
- Parallel Decoding234
- RS232 Decoding (Option)239
- I2C Decoding (Option)247
- SPI Decoding (Option)252
- CAN Decoding (Option)258
- Flexray Decoding (Option)263
Chapter 9 Reference Waveform269
- To Turn the Reference Waveform Channel On/Off270
- To Select the Current Reference Waveform Channel271
- To Set the Reference Waveform Color271
- To Select the Reference Waveform Source Channel272
- To Save and Display the Reference Waveform272
- To Adjust the Reference Waveform Display273
- To Export the Reference Waveform File273
- To Import from the Reference Waveform File274
Chapter 10 Pass/Fail Test275
- To Enable or Disable the Pass/Fail Test Function276
- To Start or Stop the Pass/Fail Test Operation276
- To Specify the Source277
- To Set the Test Mask277
  - Screen Region Mode278
  - Cursor Region Mode279
- To Turn the Test Result Display On/Off281
- To Set the Output Form of Test Failure281
- To Save the Test Mask Range283
- To Load the Test Mask Range283
Chapter 11 Waveform Recording285
- To Record Waveform Using the "Record" Mode286
- To Record Waveform Using the "Open" Mode290
  - To Play Back the Waveform Recorded291
    - Manual Playback291
    - Auto Playback292
  - To Analyze the Recorded Waveform296
    - To Set the Template (Trace Mode)297
    - To Create the Pass/Fail Test Mask (Pass/Fail Test Mode)298
Chapter 12 Display Control305
- To Specify the Display Type306
- To Set the Persistence Time307
- To Set the Waveform Brightness309
- To Specify the Screen Grid Type309
- To Set the Grid Brightness309
- To Set the Menu Display Time310
Chapter 13 Store and Recall311
- Storage System312
- Storage Type313
- To Perform Internal Storage and Recall315
- To Perform External Storage and Recall317
- Disk Management320
- Factory329
Chapter 14 System Function Setting337
- Remote Interface Configuration338
- System-Related345
Chapter 15 Remote Control359
- Remote Control Via USB360
- Remote Control Via LAN364
- Remote Control Via GPIB367
Chapter 16 Troubleshooting371
Chapter 17 Specifications375
Chapter 18 Appendix387
- Appendix A: Accessories and Options387
- Appendix B: Warranty389
Index391
