Chapter 5 To Trigger the Oscilloscope RIGOL
MSO7000/DS7000 User Guide 5-35
setting methods are available for baud rate:
 Press Baud Rate, then set the user-defined baud rate with the displayed
numeric keypad.
 Press Baud Rate, then select the preset baud rate from the available options.
The available baud rates include 50 bps, 75 bps, 110 bps, 134 bps, 150 bps, 300
bps, and etc.
 Press Baud Rate, then rotate the multifunction knob to adjust the baud
rate at a small step of 1 bps.
Trigger Mode:
In the trigger control area (Trigger) on the front panel, press Mode to quickly switch
the current trigger mode. For details, refer to descriptions in "Trigger Mode".
Trigger Parameter Setting:
Set the trigger parameter (noise rejection) under this trigger type. For details, refer
to descriptions in "Noise Rejection".
Trigger LEVEL/Threshold Level:
Rotate the Trigger LEVEL knob to adjust the trigger level/threshold level. Refer
to "Trigger LEVEL/Threshold Level". The current trigger level/threshold level
value is displayed at the upper-right corner of the screen.
