Chapter 18 Store and Load RIGOL
MSO7000/DS7000 User Guide 18-23
Lg
Operation
OFF
Source
CH1
Offset
0 U
Scale
500 mU
Invert
OFF
Ln
Operation
OFF
Source
CH1
Offset
0 U
Scale
500 mU
Invert
OFF
Exp
Operation
OFF
Source
CH1
Offset
0 U
Scale
500 mU
Invert
OFF
Abs
Operation
OFF
Source
CH1
Offset
0 U
Scale
500 mV
Invert
OFF
Low Pass
Operation
OFF
Source
CH1
Offset
0 V
Scale
500 mV
ωc
50 MHz
Invert
OFF
High Pass
Operation
OFF
Source
CH1
Offset
0 V
Scale
500 mV
ωc
50 MHz
Invert
OFF
Band Pass
Operation
OFF
Source
CH1
Offset
0 V
Scale
500 mV
ωc1
50 MHz
