Rigol MSO4000 series User Manual

RIGOL Chapter 8 Protocol Decoding
8-6 MSO4000/DS4000 User’s Guide
Note:
 The display format of the decoded data in the event table is
determined by the bus display format currently selected (refer to
“Format”).
 When adjusting the horizontal time base, the waveform displayed on
the screen will change and the total number of lines of decoding
information in the event table will change.
 The decoded data information displayed in the bus is related to the
horizontal time base. You can view the detailed information by
reducing the horizontal time base.
2) If a USB storage device is currently connected to the instrument, you can
press Export to export the decoded data list to the external USB storage
device in CSV format.
