RIGOL Chapter 13 Store and Recall
13-14 MSO4000/DS4000 User’s Guide
and press the knob to switch to “
a
A”.
2) Press Keyboard to select the “Keyboard” area, turn the multi-function
knob
to select “F” and press the knob to input the character.
4. Input the other characters
Use the same method to input the remaining characters “ilename” by referring
to step 3. Pay attention to the upper-lower case of the letters when inputting
them.
5. Modify or delete the chracters input
When inputting the name, you can modify or delete the characters input.
Press Name to select the “Name Input Area” and turn the multi-function knob
to select the character to be modified or deleted; input the desired character
by referring to step 3 or press Delete to delete the character.
Note: When the “Keyboard” area is currently selected, you can also press
Delete to delete the character currently at the cursor or the first character at
the left of the cursor (if there is no character currently at the cursor).
6. After finishing the input, press OK and the oscilloscope will create a folder or a
specified type of file with this name under the current directory.
