Chapter 17 Specifications RIGOL
MSO4000/DS4000 User’s Guide 17-9
Math Operation
Waveform
Operation
A+B, A-B, A×B, A÷B, FFT, Digital Filter, logic operation,
editable advanced operation
FFT Window Rectangle, Hanning, Hamming, Blackman
FFT Display Split, Full Screen
FFT Vertical Scale Vrms, dB
Logic Operation AND, OR, NOT, XOR
Math Function Intg, Diff, Lg, Ln, Exp, Abs, Square
, Sqrt, Sine, Cosine,
Tangent
Decoding
Number of Buses 2
Decoding Type Parallel (standard), RS232/UART (option), I2C (option), SPI
(option), CAN (option), FlexRay (option)
Parallel Combine the sample data of the source channel waveforms
as a parallel multi-channel bus and display the data as a
single bus value
RS232/UART Display the input signal(s) of the TX source channel or/and
RX source channel as bus
I2C Display the input signal of the SDA source channel as bus
SPI Display the input signal(s) of the MISO source channel
or/and MOSI source channel as bus
CAN Display the input signal of the source channel (Rx, Tx,
CAN_H, CAN_L or differential) as bus
FlexRay Display the input signal of the source channel (BP, BM or
RX/TX) as bus
