RIGOL Chapter 1 Quick Start
1-34 MSO4000/DS4000 User’s Guide
14. CH4 Status Label
Display the on/off status of CH4. When it is on, the status label is
highlighted.
Display the vertical scale of CH4 (namely the voltage value per grid of the
CH4 waveform in the vertical direction). You can use VIRTICAL
SCALE
under CH4 to modify this parameter.
Different labels may be displayed according to the current channel setting.
For example,
is displayed when the channel coupling (refer to “To
Specify the Channel Coupling”) is AC;
is displayed when the
bandwidth limit (refer to “To Specify the Bandwidth Limit”) is enabled;
is displayed when the input impedance (refer to “To Specify the Input
Impedance”) is 50 Ω.
15. Message Box
Display the prompt messages.
16. Digital Channel Status Area
Display the current on/off statuses of the 16 digital channels (D15 to D0 from
left to right). The active digital channel is highlighted in red and the other digital
channels currently turned on are displayed in green. The digital channels turned
off are displayed in gray.
Note: This function is only applicable to MSO4000 series oscilloscope.
17. Notification Area
Display the system time, sound icon, USB storage device icon and PictBridge
printer icon.
System Time: displayed in “hh:mm (hour:minute)” format. When printing
or storing the waveform, the output file will contain this time information.
Press Utility System System Time System Time to set the
system time in the following format.
yyyy-mm-dd hh:mm:ss (year-month-date hour:minute:second)
Sound Icon: when beeper is turned on,
is displayed. Press Utility
Sound to turn the beeper on or off.
USB Storage Device Icon: when the oscilloscope detects a USB storage
device, is displayed.
PictBridge Printer Icon: when the oscilloscope is correctly connected to a
