RIGOL Chapter 5 To Trigger the Oscilloscope

5-56 MSO8000 User Guide

If you enable Zone A, select CH1 as Source A, and select "Not intersect" as the

condition, the following figure is displayed.

Tip

If you enable both Trigger zone A and Trigger zone B, then perform the "A&&B"

operation, and it will become the final trigger condition.
