Chapter 3 Functions of the Front Panel of RTSA RIGOL
RSA5000 User Guide 3-9
Table 3-7 Acquisition Time
Parameter
Remarks
Default
30.00 ms
Range
0 s to 40 s
Unit
s, ms, μs, ns, ps
Knob Step
acquisition time/100, Min = 1 μs
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
Acq Time Auto (PvT)
Sets the acquisition time for the PvT analysis to "Auto" or "Manual".
Remarks:
⚫ When "Auto" is selected, the acquisition time (PvT) adopts the default value.
⚫ When "Manual" is selected, the acquisition time (PvT) can be set manually
within its available range.
Continue
In RTSA mode, the continuous sweep function is logically same as that in GPSA mode.
Press this key to perform the continuous sweep or measurement operation. This
setting is global to all the activated traces and the detector types.
For details, refer to "Continue" in Chapter 2.
Single
In RTSA mode, the single sweep function is logically same as that in GPSA mode.
Press this key to perform the single sweep or measurement operation. This setting is
global to all the activated traces.
Note: In RTSA mode, when performing the single measurement, the instrument will
not stop sweeping until the sweep count has reached N. Wherein, N is determined by
the result of "Avg. Number x (Acq/Trigger)" in the current measurement mode.
During the single measurement, the trace data in the Normal view is updated for
display in a real-time manner, whereas the trace history data in the Spectrogram
view are not cleared.
For details, refer to "Single" in Chapter 2.
